Reliable 5V Power, Engineered for Precision

Name: 5V SMPS Power Supply
Brand: EazyIoT
Availability: InStock

High-efficiency SMPS design delivering stable 5V output for your critical applications.

What is a 5V Supply?

A 5V Supply is a regulated power source that provides a stable 5 volts DC output, commonly used in electronics, embedded systems, and consumer devices. Modern 5V supplies are often built using Switched-Mode Power Supply (SMPS) technology, which ensures high efficiency, compact size, and minimal heat generation compared to traditional linear regulators.

Engineered for Efficiency, Reliability, and Safety

Maintains a precise 5V level for sensitive electronics.
SMPS-based designs reduce power loss and heat.
Can accept varying input voltages while delivering consistent output.
Suitable for space constrained applications.
Used in industrial systems, IoT devices, and consumer electronics.

Electrical Specifications

Input Voltage Range: 180 – 440V AC, 50/60 Hz
Input Frequency: 47 – 63 Hz
Input Protection: Fuse (internal), surge protection
Output Voltage: 5V ± 5% DC
Output Current: Up to 2A continuous (Without battery backup)
Output Power: 10W (max)
Line Regulation: ±1% max
Load Regulation: ±2% max
Hold-up Time: >10ms at full load
Ripple & Noise: <100 mVp-p @ full load (20 MHz bandwidth)
Indicators: Bi-color LED to indicate DC output status, Red LED – AC supply ON, Green LED – On battery backup
Output Control: Output ON/OFF switch
Input/output Connectors: Pluggable connectors

Product Code	Description	Communication	Datasheet
5V-SMPS-BB	5V SMPS with Battery Backup	Lorem Ipsum	Download PDF
5V-SMPS-NB	5V SMPS without Battery Backup	Lorem Ipsum	Download PDF

Optional Battery Backup for Uninterrupted 5V Power

Integrated battery ensures continuous operation during power outages with built-in protection and fast charging.

Parameters	Specifications
Output Voltage	5V
Output Current	1A max
Backup Type	Li-ion battery
Battery Voltage	3.7V (internally boosted to 5V)
Battery Capacity	1000 mAh
Backup Duration	≥ 2 hours at 500mA load
Charging Method	Constant current / constant voltage (CC/CV)
Charging Current	350 mA
Charging Time	≈ 3–4 hours (depending on battery capacity)
Battery Protection	Over-charge, over-discharge, short circuit, thermal protection
